NITECORE TM20K Ultra High Performance Tactical Searchlight Emits 20,000 lumens
4.5 out of 5 based on 212 user ratings

NITECORE TM20K Ultra High Performance Tactical Searchlight Emits 20,000 lumens

by: Nitecore

CAD USD

Please notify us if you want to pay in USD. We will email you a separate Paypal invoice in USD.



Secure payments by:Pay with Paypal, Visa or Mastercard


Overview :

Equipped with 19 x CREE XP-L2 LEDs, the NITECORE TM20K is endowed with an astonishingly high performance of a max output of 20,000 lumens, a max peak beam intensity of 22,200cd and a max throw of 290 meters. The TM20K is designed with a flat and compact body featuring 20,000 lumens within your palm. Built from unibody CNC technology, it is lightweight, rigid and fast cooling, suitable for outdoor searching, industrial searching, self-defense, rescuing and indoor searching.



The TM20K utilizes an innovative operating system—User Mode Selection Toggle Switch available for selecting Lockout Mode, Daily Mode, and Tactical Mode. It is equipped with a metal Power Button, a Mode Button for switching between 4 brightness levels, spotlight and floodlight, and ambidextrous tactical buttons to perform the same functions.

 The TM20K is also designed with STROBE READY™ and TurboReady™ for instantly accessing to 20,000 lumens, which enables an abrupt disturbance to your adversary during the day or at night.

 With built-in 9,600mAh energizing 21700 Li-ion batteries, the TM20K is available to emit 320 lumens output on ULTRALOW with a max runtime of 13 hours for daily use. The USB-C charging port is available for QC mode to fully charge in 4.5 hours.

 The TM20K is designed with excellent heat dissipation performance: integrated ATR technology, CNC machined unibody design to improve the heat dissipation, aero grade aluminum alloy construction with outstanding thermal conduction, and cooling fins on the head.

 The deep carry pocket clip for attaching to the backpack, pocket and MOLLE System is convenient to store and carry. The included magnetic holster is ideal for protecting the flashlight. The TM20K is all weather applicable as IP68 rated, which is effectively protected against the complex outdoor environment.





LED Brightness Level Waterproof Specifications (Width, Length, Diameter) Weight Battery
19 CREE XP-L2  LEDs
4 level Brightness; Spotlight & Floodlight IP68, 2m
 145.5mmx50mmx50mmx26mm(5.73"x1.97"x1.02")(including clip)
14.89oz(Clip Included)
Built-in 4,800mAh 21700 rechargeable Li-ion battery
FL1 STANDARD General Mode
Turbo High Mid Low Ultra-low Spot Light Flood Light Strobe
Output (lumens) 20,000 3,100 1,900 1,050 320 1200 lumens 1,800 lumens 20,000 luens
Runtime  *---- *45min 1h45min 4h15min 13h 3 h 30 min 2 h
Beam Distance 290m 270m 260m 190m 120m 260 m 73 m
Peak Beam Intensity
22,200cd
18,500cd 17,100cd 9,500cd 3,900cd 17,000cd 1,340 cd
Impact Resistance (1m)

NOTICE: The stated data is measured using 2 x 21700 Li- ion Battery (3.6V 4,800mAh) under laboratory conditions. The data may vary in real world use due to different battery usage or environmental conditions. *The data is tested without temperature regulation.



    • Utilizes 19 x CREE XP-L2 LEDs with a max output of 20,000 lumens
    •  Max peak beam intensity of 22,200cd and max throw of 290 meters

    • Lightweight, rigid and fast cooling tube built from unibody CNC technology

    •  Built-in 2 x 21700 rechargeable Li-ion batteries (9,600mAh in total)

    • Intelligent Li-ion battery charging circuit with USB-C charging port

    • Ambidextrous tactical buttons specially designed for tactical activities
    • Interchangeable STROBE READY'"' (Patent No. ZL201320545349.4) and TurboReadyTM settings
    • STROBE Mode uses randomly changing frequencies for stronger dizzying effects

    • Highly efficient constant current circuit provides stable output up to 13 hours
    • Integrated Advanced Temperature Regulation (Patent No. ZL201510534543.6)
    • Optical lenses with double-sided scratch resistant coating
    • Constructed from aero grade aluminum alloy

    • HA III military grade hard-anodized finish
    • Waterproof and dustproof rating in accordance with IP68 (2 meters submersible)

    • Impact resistant to 1 meter

    • Tail stand capability
    • Size: 145.5mm x 50mm x (50mmx26mm)-[5.73"x1.97"x(1.97"x1.02")]
    • Weight: 422g (14.89oz) including the clip
    • USB Type-C Charging cable
    • Lanyard
    • Holster
